Investigation on Seismic Damage of Religious Buildings in MS 7.9 Myanmar Earthquake
-
摘要: 2024年3月28日，缅甸发生MS7.9地震。地震造成大量建筑受损，其中包括许多宗教建筑。由于历史原因，缅甸境内存在大量佛教寺庙、清真寺等宗教场所，宗教场所中一般有木结构、砌体结构、框架结构和钢结构。总体上看，框架结构和钢结构基本为近年新建建筑，部分框架建筑的设计受使用功能的影响，出现了刚度分配不均匀的现象，削弱了房屋的抗震性能，出现了严重的震害；钢结构的震害主要出现在填充墙上；木结构和砌体结构一般修建年代较早，木结构出现震害的主要原因是木构件与墙体之间无有效连接，木构件与墙体会相互作用，导致木结构墙体开裂、外闪；几乎所有的砌体结构均无抗震设防措施，而且，使用年限长，未进行有效加固，施工质量差等原因导致许多砌体结构在地震中受损。本文通过对缅甸13个佛寺和1个清真寺进行了实地调查，对宗教建筑、佛塔的震害进行了总结和分析，以期为震后恢复重建和已有房屋的加固设防提供思路，同时对国内同类建筑的抗震能力提升提供参考。Abstract: An MS 7.9 earthquake occurred on Myanmar in March 28, 2025, causing massive buildings damaged, including many religious buildings. Due to the historic factors, there are many Buddhist temples, mosques in Myanmar and these buildings in religious places usually include timber structure, masonry structure, RC frame structure and steel structure.Timber structures and masonry structures were usually built long time ago, almost all masonry structures lack of seismic measures, causing poor seismic resistance; RC frame structures and steel structures were built in recent years, some RC frame structures occurred irregular distribution of stiffness due to usage function, weakened the seismic ability, occurred severely seismic damage; the seismic damage of steel structure mainly occurred in infill walls. The seismic damage of timber structures are cracks on the infill walls and collapse of infill walls because of the weak connection and interaction between infill wall and timber part; almost all of masonry structures lack of seismic measures,besides, factors like long service time, without reinforced effectively, poor construction equality caused many masonry buildings damaged in this earthquake. According to the field investigation, 13 Buddhist temples and 1 mosque were investigated, the characteristics of seismic damage of religious buildings and pagodas were summarized and analyzed, in order to provide reconstruction and reinforcement with suggestions, meanwhile, reference can be provided to improve the seismic ability of similar buildings in our country.
-
Key words:
- Earthquake /
- Myanmar /
- Religious buildings /
- Reinforcement /
- Seismic damage
-
图 1 彪关镇乌塔拉扬寺庙大门震害
Figure 1. Seismic damage of the main gate of U Thar Lyaung Temple, Paukkan Town
图 5 A建筑平面图、内部震害和木结构B侧面震害
Figure 5. Plan of building A, internal seismic damage of building A and lateral seismic damage of timber structure B
图 7 砌体结构、木结构和围墙的震害
Figure 7. Seismic damage of masonry structure,timber structure and wall
图 16 佛塔的木结构和框架结构震害
Figure 16. Seismic damage of timber structure and RC frame structure of the pagodas
表 1 调查点列表
Table 1. The list of investigation spots
序号 省份 县 建筑名称 描述 经纬度 震中距/km 所处烈度区 1 勃固省 东吁县 彪关镇乌塔拉扬修道院寺 围墙破坏 96.43°E
18.49°N374.64 Ⅵ度 2 坎塔清真寺 1栋砌体结构倒塌
1栋框架结构严重破坏96.43°E
18.95°N324.88 Ⅵ度 3 耶塔斯亚镇帕亚科内村寺庙 1栋框架结构轻微破坏
1栋木结构轻微破坏
3座佛塔轻微破坏96.05°E
19.82°N224.83 Ⅵ度 4 信仰之光寺庙 1栋框架结构毁坏
1栋木结构破坏96.25°E
19.77°N233.467 Ⅶ度 5 维鲁万冥想寺庙 1栋砌体结构轻微破坏
1栋砌体结构倒塌
1栋木结构轻微破坏96.43°E
18.94°N326.44 Ⅵ度 6 曼德勒省 敏建县 宾齐镇以东3 km处村庄寺庙 1栋木结构轻微破坏
2栋砌体结构轻微破坏
寺院内围墙倒塌95.94°E
21.41°N48.74 Ⅷ度 7 皎施县 密达镇区帕克缅村斯里曼塔拉寺 多座佛塔倒塌 96.09°E
21.44°N48.14 Ⅷ度 8 德达乌镇以东1 km寺庙 1栋佛塔轻微破坏
1栋钢结构轻微破坏96.20°E
21.45°N51.21 Ⅷ度 9 皎施镇蒲甘寺 多栋砌体结构毁坏
多座佛塔严重破坏96.19°E
21.6037.27 Ⅷ度 10 曼德勒市 山达穆尼佛塔 多栋佛塔破坏 96.11°E
22.00°N23.79 Ⅷ度 11 实皆省 实皆市 和平宝石寺庙 1栋框架结构毁坏
2栋木结构毁坏95.98°E
21.906.90 Ⅸ度 12 康穆达佛塔 2栋佛塔毁坏
主佛塔轻微破坏95.94°E
21.94°N9.56 Ⅸ度 13 泰拉·纽昌寺庙 1栋框架结构毁坏
1栋框架结构承重构件严重破坏95.98°E
21.90°N6.90 Ⅸ度 14 美丽宝塔 1栋框架结构中等破坏
1栋框架结构水塔毁坏
1栋砌体结构毁坏95.99°E
21.89°N6.97 Ⅸ度
下载: 导出CSV
-
丁保安, 2017. 既有砌体结构的抗震鉴定与加固性能研究. 镇江: 江苏大学.Ding B. A. , 2017. Study on seismic appraisal and strengthening performance of existing masonry structure. Zhenjiang: Jiangsu University. (in Chinese) 刘建辉, 孙艺璇, 柏亚双等, 2023. 宁蒗5.5级地震村镇房屋震害调查与分析. 地震工程与工程振动, 43(1): 128−138. doi: 10.13197/j.eeed.2023.0113Liu J. H., Sun Y. X., Bai Y. S., et al., 2023. Investigation and analysis of the rural building damage of Ninglang MS5.5 earthquake. Earthquake Engineering and Engineering Dynamics, 43(1): 128−138. (in Chinese) doi: 10.13197/j.eeed.2023.0113 卢晨虎, 宋波, 王满生等, 2024. 考虑砌筑砂浆劣化的老旧砌体结构抗震性能分析. 建筑结构, 54(9): 139−143. doi: 10.19701/j.jzjg.20212141Lu C. H., Song B., Wang M. S., et al., 2024. Seismic performance analysis of old masonry structure considering deterioration of masonry mortar. Building Structure, 54(9): 139−143. (in Chinese) doi: 10.19701/j.jzjg.20212141 马小平, 孙艳萍, 陈文凯等, 2020. 甘肃夏河MS5.7地震烈度评定及震害特征分析. 地震工程学报, 42(3): 777−783. doi: 10.3969/j.issn.1000-0844.2020.03.777Ma X. P., Sun Y. P., Chen W. K., et al., 2020. Seismic intensity evaluation and damage characteristics of Xiahe, Gansu MS5.7 earthquake. China Earthquake Engineering Journal, 42(3): 777−783. (in Chinese) doi: 10.3969/j.issn.1000-0844.2020.03.777 潘毅, 季晨龙, 王超等, 2012. 日本地震中钢筋混凝土框架结构震害及分析. 工程抗震与加固改造, 34(4): 122−127, 133. doi: 10.3969/j.issn.1002-8412.2012.04.023Pan Y., Ji C. L., Wang C, et al., 2012. Seismic damage analysis of the reinforced concrete frame structures in Japanese Earthquake. Earthquake Resistant Engineering and Retrofitting, 34(4): 122−127,133. (in Chinese) doi: 10.3969/j.issn.1002-8412.2012.04.023 曲哲, 钟江荣, 孙景江, 2014. 四川芦山7.0级地震中非抗震设防民居震害特征. 建筑结构学报, 35(5): 157−164. doi: 10.14006/j.jzjgxb.2014.05.003Qu Z., Zhong J. R., Sun J. J., 2014. Seismic damages of non-seismic design residential houses in the M7.0 Lushan Earthquake. Journal of Building Structures, 35(5): 157−164. (in Chinese) doi: 10.14006/j.jzjgxb.2014.05.003 任辰昊, 杜一鹏, 史庆轩等, 2025. 西藏定日6.8级地震拉孜县Ⅶ度区建筑震害调查与分析. 震灾防御技术, 20(2): 243−253. doi: 10.11899/zzfy20250037Ren C. H., Du Y. P., Shi Q. X., et al., 2025. Investigation and analysis of building seismic damages in the seismic intensity Ⅶ Area in Lazi County caused by M6.8 Dingri Earthquake. Technology for Earthquake Disaster Prevention, 20(2): 243−253. (in Chinese) doi: 10.11899/zzfy20250037 王威, 周颖, 梁兴文等, 2010. 砌体结构在2008汶川大地震中的震害经验. 地震工程与工程振动, 30(1): 60−68. doi: 10.13197/j.eeev.2010.01.016Wang W., Zhou Y., Liang X. W., et al., 2010. Lessons learnt from masonry structural damage in 2008 Wenchuan earthquake. Journal of Earthquake Engineering and Engineering Vibration, 30(1): 60−68. (in Chinese) doi: 10.13197/j.eeev.2010.01.016 王振, 郭晓云, 郭絮絮等, 2018. RC框架结构典型震害及抗震性能研究. 工程抗震与加固改造, 40(2): 79−86. doi: 10.16226/j.issn.1002-8412.2018.02.012Wang Z., Guo X. Y., Guo X. X., et al., 2018. A review on seismic damage and behavior of RC frame structure. Earthquake Resistant Engineering and Retrofitting, 40(2): 79−86. (in Chinese) doi: 10.16226/j.issn.1002-8412.2018.02.012 信任, 王亚军, 王庆霖等, 2015. 砌体结构开洞墙体平面应力有限元分析. 武汉大学学报(工学版), 48(S1): 62−65.Xin R., Wang Y. J., Wang Q. L., et al., 2015. Finite element analysis of plane stress in masonry structure walls with openings under seismic action. Engineering Journal of Wuhan University, 48(S1): 62−65. (in Chinese) 俞瑞芳, 谢志强, 彭凌云等, 2014. 砌体强度对自建民居抗震性能的影响分析. 振动与冲击, 33(11): 6−11. doi: 10.13465/j.cnki.jvs.2014.11.002Yu R. F., Xie Z. Q., Peng L. Y., et al., 2014. Effect of masonry strength on aseismic performance of self-built dwellings. Journal of Vibration and Shock, 33(11): 6−11. (in Chinese) doi: 10.13465/j.cnki.jvs.2014.11.002 周洋, 张学坦, 郭迅, 2025. 晋东南农村建筑抗震性能分析与易损性矩阵构建. 震灾防御技术, 20(1): 97−107. doi: 10.11899/zzfy20240047Zhou Y., Zhang X. T., Guo X., 2025. Seismic performance analysis and vulnerability matrix construction for rural buildings in southeast Shanxi Province. Technology for Earthquake Disaster Prevention, 20(1): 97−107. (in Chinese) doi: 10.11899/zzfy20240047 -
