Quaternary Activity Identification in the Huaibei Section of Subei Fault
-
摘要: 通过浅层地震反射勘探、钻孔联合剖面探测和新构造年代学测试等方法，对宿北断裂淮北段的第四纪活动习性进行了研究。浅层地震反射勘探结果表明，宿北断裂淮北段断错了第四纪地层，断面波发育，断层上盘地层受断层牵引变形明显，属于区域性的大断裂。钻孔联合剖面探测结合新构造年代学测试结果显示，宿北断裂淮北段最新活动时代为中更新世中晚期，其在中更新世中晚期以来的最大垂直滑动速率约为0.011 mm/a，中更新世以来的最大垂直滑动速率约为0.009 mm/a，表明宿北断裂淮北段在中更新世以来的活动强度较低且没有显著增强的趋势。宿北断裂是徐宿弧形构造的伴生构造，二者具有相同的新老构造运动特征。宿北断裂早期以左行走滑兼逆冲为主，后受新构造运动的影响，宿北断裂淮北段和宿州段在进入第四纪以来可能以青龙山断裂附近为界，表现出较明显的“淮北段较强、宿州段稍弱”差异化张性活动特征。研究结果对淮北市和宿州市的地震灾害风险评估具有重要指导价值。Abstract: The Quaternary activity habits of the Huaibei section of Subei fault were studied by means of shallow seismic reflection exploration, borehole joint profile detection and neotectonic chronology test. The results of shallow seismic reflection exploration show that the Huaibei section of the Subei fault has broken the Quaternary strata, the section wave is developed, and the upper wall of the fault is obviously deformed by the fault traction, which belongs to the regional large fault. The results of borehole combined profile detection and neotectonic chronology test show that the latest activity age of the Huaibei section of Subei fault is in the middle and late Middle Pleistocene. The maximum vertical slip rate since the middle and late Middle Pleistocene is about 0.011 mm/a, and the maximum vertical slip rate since the middle Pleistocene is about 0.009 mm/a, indicating that the activity intensity of the Huaibei section of Subei fault since the middle Pleistocene is low and there is no significant increase trend. Subei fault is an associated structure of Xusu tectonic arc, both of which have the same characteristics of new and old tectonic movements. In the early stage of Subei fault, it was dominated by left-lateral strike-slip and thrust. Later, under the influence of neotectonic movement, the Huaibei section and Suzhou section of Subei fault have been bounded by Qinglongshan fault since the Quaternary period, showing obvious differential tensile activity characteristics of ' strong in the Huaibei section and weak in the Suzhou section '. The research results have important guiding value for the earthquake disaster risk assessment of Huaibei City and Suzhou City.1)
1 2 北京防灾科技有限公司，2023. 淮北市活动断层探测与地震危险性评价项目-标准钻孔探测与第四纪地层剖面建立报告.2)2 3 北京防灾科技有限公司，2023. 淮北市活动断层探测与地震危险性评价项目-标准钻孔探测与第四纪地层剖面建立报告.3)3 4 北京防灾科技有限公司，2023. 淮北市活动断层探测与地震危险性评价项目-标准钻孔探测与第四纪地层剖面建立报告.4)4 5 安徽省震灾风险防治中心（安徽省地震工程研究院），2022. 宿州市城市活动断层探测及危险性评价项目子专题6-目标断层的晚第四纪活动性鉴定野外工作总结报告. -
图 1 研究区及邻区地质构造简图
Figure 1. Schematic diagram of geological structure in the study area and adjacent areas
图 2 L1测线浅层地震反射勘探时间剖面和深度解释剖面图
Figure 2. Seismic reflection exploration time profile and depth interpretation profile of line L1
图 3 L2测线浅层地震反射勘探反射勘探时间剖面和深度解释剖面图
Figure 3. Seismic reflection exploration time profile and depth interpretation profile of line L2
图 4 ZL-1钻孔联合剖面综合解释图
Figure 4. Comprehensive interpretation of ZL-1 borehole combined profile
图 5 宿北断裂局部展布特征图
Figure 5. The local distribution characteristic map of the Subei fault
表 1 浅层地震反射勘探测线参数
Table 1. Line parameters of shallow seismic reflection exploration
测线编号 起点坐标 终点坐标 测线长度/km 物理点数 东经 北纬 东经 北纬 L1 116°38'56" 33°43'38" 116°39′37″ 33°46'54" 6.018 609 L2 116°45′56″ 33°42′49″ 116°46′43″ 33°45′09″ 4.268 433
下载: 导出CSV
表 2 ZL-1钻孔联合剖面各钻孔信息
Table 2. Borehole information of ZL-1 borehole joint section
钻孔编号 坐标 孔深/m 东经 北纬 zk1 116°39′ 16.82765 ″33°45′ 17.60565 ″100 zk2 116°39′ 17.47848 ″33°45′ 20.47438 ″125 zk3 116°39′ 17.67588 ″33°45′ 18.97355 ″124 zk4 116°39′ 17.80851 ″33°45′ 19.73192 ″125 zk5 116°39′ 17.84205 ″33°45′ 20.15344 ″114 zk6 116°39′ 17.75571 ″33°45′ 20.27086 ″110 zk7 116°39′ 17.25123 ″33°45′ 18.29945 ″120 zk8 116°39′ 17.04315 ″33°45′ 17.96742 ″120.5
下载: 导出CSV
表 3 光释光年代学样品测试结果
Table 3. The dating rusults of OSL samples
序号 编号 深度/m U Th K 年龄/ka 1 O1 6.8 2.81±0.39 13.94±0.76 1.76±0.06 49.79±3.32 2 O2 12.4 1.62±0.19 9.60±0.61 1.81±0.07 73.98±4.88 3 O3 19.8 2.54±0.26 12.40±1.18 1.77±0.08 110.45±9.39 4 O4 27.6 1.86±0.20 12.89±1.14 2.25±0.11 116.51±10.12 5 O5 38.4 2.30±0.27 12.55±1.17 1.64±0.06 112.80±10.52 6 O6 18.8 2.59±0.28 11.40±1.14 1.71±0.08 97.54±8.05 7 O7 28.9 1.70±0.19 12.66±1.06 1.79±0.07 103.28±8.57 8 O8 37.4 1.70±0.20 12.66±1.18 1.76±0.05 108.45±8.53 9 O9 9.1 1.95±0.26 13.70±0.97 2.22±0.08 72.95±5.78 10 O10 18.3 2.66±0.36 13.09±1.13 1.79±0.08 75.48±6.97 11 O11 29.5 2.05±0.24 11.20±0.83 2.05±0.08 119.49±11.70 12 O12 7.5 1.77±0.26 15.36±1.28 2.16±0.09 70.83±5.45 13 O13 18.9 2.26±0.32 11.28±1.04 1.94±0.08 72.42±5.61 14 O14 27.3 1.48±0.21 15.51±1.48 1.97±0.07 108.33±8.65
下载: 导出CSV
表 4 电子自旋共振年代学样品测试结果
Table 4. The dating rusults of ESR samples
序号 编号 深度/m U Th K 年龄/ka 1 E1 81.2 1.45±0.06 8.03±0.16 2.36±0.09 438±47 2 E2 108.3 1.49±0.06 8.30±0.17 2.24±0.09 608±63 3 E3 112.9 2.46±0.10 7.66±0.15 1.99±0.08 648±70
下载: 导出CSV
-
陈昌武, 高远, 2016. 利用地震资料研究活断层的方法和对煤矿安全开采的意义. 西部探矿工程, 28(10): 89−92, 98.Chen C. W., Gao Y., 2016. Method for studying active fault by using seismic data and its significance of safe mining in coal mine. West-China Exploration Engineering, 28(10): 89−92,98. (in Chinese) 陈俊, 2016. 徐淮地区构造变形特征与形成机制研究. 合肥: 合肥工业大学.Chen J., 2016. Research of structural characteristics and deformation mechanism in the Xuhuai region. Hefei: Hefei University of Technology. (in Chinese) 方婷, 2017. 安徽淮北煤田构造特征和形成机制. 南京: 南京大学.Fang T., 2017. The structure features and forming mechanism of the Huaibei coalfield. Nanjing: Nanjing University. (in Chinese) 雷启云, 柴炽章, 孟广魁等, 2011. 隐伏活断层钻孔联合剖面对折定位方法. 地震地质, 33(1): 45−55.Lei Q. Y., Chai C. Z., Meng G. K., et al., 2011. Method of locating buried active fault by composite drilling section doubling exploration. Seismology and Geology, 33(1): 45−55. (in Chinese) 李法浩, 2019. 华北板块东南缘徐淮孤形构造带的物理模拟研究. 南京: 南京大学.Li F. H., 2019. Physical modeling of Xu-Huai arc structure on the southeastern margin of North China Block. Nanjing: Nanjing University. (in Chinese) 李万程, 1996. 徐淮弧的成因与煤炭资源远景. 中国煤田地质, (2): 1−4.Li W. C., 1996. The genetics and coal resource prospect of Xu-Hvai arc. Coal Geology of China, (2): 1−4. (in Chinese) 李岩, 王新建, 2011. 三维地震在淮北煤田采区勘探中的应用. 西部探矿工程, 23(2): 165−166, 169. 吕凡家, 2017. 安徽宿北断裂凹陷带内地热资源勘查前景分析. 西部探矿工程, 29(9): 142−143, 148. 马公伟, 1992. 对徐宿弧形构造成因的新认识. 中国区域地质, (1): 83−87.Ma G. W., 1992. New recognition on the genesis of the Xuzhou-Suoxian arcuate structure. Geological Bulletin of China, (1): 83−87. (in Chinese) 欧云云, 2015. 淮北平原煤田三维地震勘探. 西部探矿工程, 27(11): 143−146. doi: 10.3969/j.issn.1004-5716.2015.11.046 庞琪沛, 吴云龙, 张毅等, 2024. 淮北及邻区地壳均衡异常与构造背景. 地球物理学报, 67(9): 3341−3356.Pang Q. P., Wu Y. L., Zhang Y., et al., 2024. Isostasic anomaly and tectonic background in Huaibei city, Anhui and its adjacent areas. Chinese Journal of Geophysics, 67(9): 3341−3356. (in Chinese) 彭涛, 2015. 淮北煤田断裂构造系统及其形成演化机理. 淮南: 安徽理工大学.Peng T., 2015. The fault system and its evolution mechanism of Huaibei coalfield. Huainan: Anhui University of Science and Technology. (in Chinese) 舒良树, 吴俊奇, 刘道忠, 1994. 徐宿地区推覆构造. 南京大学学报, 30(4): 638−647.Shu L. S., Wu J. Q., Liu D. Z., 1994. Thrust tectonics of Xuzhou-Suzhou region, eastern China. Journal of Nanjing University (Natural Science Edition), 30(4): 638−647. (in Chinese) 王乐乐, 周虎, 2019. 符离集断裂导岩控矿作用分析. 现代矿业, 35(9): 26−28, 34.Wang L. L., Zhou H., 2019. Analysis of ore-controlling effect of Fuliji fault-guided rock. Modern Mining, 35(9): 26−28,34. (in Chinese) 王琦, 高远, 范景坤, 2010. 三维地震勘探技术在淮北矿区的应用. 中国煤炭地质, 22(8): 61−66.Wang Q., Gao Y., Fan J. K., 2010. Application of 3D seismic prospecting technology in Huaibei mining area. Coal Geology of China, 22(8): 61−66. (in Chinese) 徐传田, 2023. 淮北矿区地质构造对煤层瓦斯赋存的控制作用及防治技术研究. 徐州: 中国矿业大学.Xu C. T., 2023. Study on the control effect of tectonics on coal seam gas occurrence and prevention techniques in Huaibei mining area. Xuzhou: China University of Mining and Technology. (in Chinese) 徐昊铭, 2013. 淮北地区宿北断裂两侧成矿特征研究−−基于岩石地球化学的分析. 北京: 中国地质大学(北京).Xu H. M., 2013. The research of metallogenic characteristics on the two sides of Subei fault in Huaibei area−Based on the analysis of geochemical. Beijing: China University of Geosciences (Beijing). (in Chinese) 曾博, 2022. 徐宿弧形构造形成机制及煤层气富集规律. 徐州: 中国矿业大学.Zeng B., 2022. Formational mechanism of the Xu-Su arcuate structures and enrichment law of coalbed methane. Xuzhou: China University of Mining and Technology. (in Chinese) 张杰, 2023. 淮北煤田岩溶水水文地球化学演化及其对地热的指示意义. 合肥: 合肥工业大学.Zhang J., 2023. Hydrogeochemical evolution of karst water and its indicative significance for geothermal in Huaibei coalfield. Hefei: Hefei University of Technology. (in Chinese) 张鹏, 李丽梅, 刘建达等, 2015. 徐州废黄河断裂的第四纪活动性. 地震地质, 37(1): 208−221.Zhang P., Li L. M., Liu J. D., et al., 2015. Research on the characteristics of Quaternary activities of Feihuanghe fault in Xuzhou area. Seismology and Geology, 37(1): 208−221. (in Chinese) 张岳桥, 董树文, 2008. 郯庐断裂带中生代构造演化史: 进展与新认识. 地质通报, 27(9): 1371−1390.Zhang Y. Q., Dong S. W., 2008. Mesozoic tectonic evolution history of the Tan-Lu fault zone, China: advances and new under standing. Geological Bulletin of China, 27(9): 1371−1390. (in Chinese) 赵立明, 2015. 淮北矿区高密度三维地震勘探岩性解释技术研究. 徐州: 中国矿业大学.Zhao L. M., 2015. Study on lithology interpretation technology of high-density 3D seismic data in Huaibei mining area. Xuzhou: China University of Mining and Technology. (in Chinese) 赵婷婷, 2010. 淮北煤田煤系岩性特征研讨. 科技风, (2): 150, 164. 周露, 2021. 皖北矿区断裂构造发育特征及控水作用研究. 淮南: 安徽理工大学.Zhou L., 2021. Study on development characteristics of fault structure and water control in mining area of northern Anhui province. Huainan: Anhui University of Science and Technology. (in Chinese) 朱将波, 汪启年, 刘玉泉等, 2024. 蚌埠−淮北地区电性结构及地质意义. 物探与化探, 48(4): 971−978.Zhu J. B., Wang Q. N., Liu Y. Q., et al., 2024. Electrical structure of the Bengbu-Huaibei area and its geological implications. Geophysical and Geochemical Exploration, 48(4): 971−978. (in Chinese) Pang Q. P., Wu Y. L., Chu R. S., et al., 2024. Deep structural characteristics and dynamic significance of the Southeastern margin of the North China Craton: Insights from gravity/GNSS/seismic observations. Tectonophysics, 874: 230243. Zheng R. Y., Yao Y. S., Shen J., et al., 2025. Front margin tectonic deformation characteristics of the Xu−Su arc tectonic belt and its tectonic implications. Applied Geophysics, 22(3): 784-795+896. [2025-04-17]. https://link.springer.com/article/ 10.1007/s11770-024-1164-x. DOI: 10.1007/s11770-024-1164-x. -
