双级模块式加筋土挡墙动力响应数值分析

祁高; 李思汉; 蔡博渊; 蔡晓光; 黄鑫; 王磊

doi:10.11899/zzfy20250062

双级模块式加筋土挡墙动力响应数值分析

doi: 10.11899/zzfy20250062

祁高^1,,
李思汉^{2, 3, 4, ,},
蔡博渊²,
蔡晓光^{3, 4, 5},
黄鑫^{2, 3, 4},
王磊⁶

1.
江苏省地质局第一地质大队, 南京 210041
2.
防灾科技学院, 防灾减灾工程学院, 河北廊坊 065201
3.
河北省地震灾害防御与风险评价重点实验室, 河北廊坊 065201
4.
廊坊市加筋土结构研发与应用重点实验室, 河北廊坊 065201
5.
中国地震灾害防御中心, 北京 100029
6.
江苏南京地质工程勘察院, 南京 210041

基金项目: 江苏省地质工程环境智能监控工程研究中心开放基金（2023-ZNJKJJ-06）；地震科技星火计划青年项目（XH23067 YA）；河北省高等学校科学研究青年拔尖人才计划项目（BJK2024034）

详细信息

作者简介:
祁高，男，生于1992年。工程师。主要从事地质工程方面的工作。E-mail：294990420@qq.com

通讯作者:
李思汉，男，生于1992年。副教授。主要从事岩土地震工程方面的教学和研究工作。E-mail：lisihan@st.cidp.edu.cn

计量
- 文章访问数: 19
- HTML全文浏览量: 2
- PDF下载量: 4
- 被引次数: 0
出版历程
- 收稿日期: 2025-04-28
- 录用日期: 2025-05-14
- 修回日期: 2025-04-28
- 网络出版日期: 2025-07-23

Numerical Analysis of Dynamic Response of Two-tiered Modular Reinforced Soil Retaining Wall

Qi Gao^1
,,
Li Sihan^{2, 3, 4
, ,},
Cai Boyuan²,
Cai Xiaoguang^{3, 4, 5},
Huang Xin^{2, 3, 4},
Wang Lei⁶

1.
The First Geological Brigade of Jiangsu Geological Bureau, Nanjing 210041, China
2.
College of Disaster Prevention and Mitigation Engineering, Institute of Disaster Prevention, Langfang 065201, Hebei, China
3.
Hebei Key Laboratory of Earthquake Disaster Prevention and Risk Assessment, langfang 065201, Hebei, China
4.
Langfang City Key Laboratory of Research and Application of Geosynthetic Reinforced Soil Structure, Langfang 065201, Hebei, China
5.
China Earthquake Disaster Prevention Center, Beijing 100029, China
6.
Jiangsu Nanjing Geological Engineering Investigation Institute, Nanjing 210041, China

摘要

摘要: 针对地震作用下双级加筋土挡墙临界台阶宽度不明、上下阶墙高选取随意，不利于加筋土挡墙推广应用的情况，基于双级模块式加筋土挡墙的振动台试验结果，建立FLAC 3D数值模型，研究了不同台阶宽度（10、20 、30、40、50、60 cm）、不同墙高比（上下阶墙体分别为3/7、4/6、1/1、6/4、7/3）下加筋土挡墙的墙面位移、加速度响应及地震土压力分布情况。结果表明，面板位移随台阶宽度的增加先减小后增大，最小值出现在台阶宽度为50 cm工况中；加速度放大系数沿墙高非线性递增，上阶挡墙在台阶宽度为40 cm和60 cm时出现加速度响应衰减；下阶墙体土压力在台阶宽度为50 cm时数值最小；上下阶挡墙墙高比为4/6时，墙面峰值位移最小；墙高比为6/4时，上阶挡墙的加速度放大系数最大，墙高比为1/1时，下阶挡墙的加速度放大系数最大；墙高比为7/3时，上阶挡墙的地震土压力值最大，墙高比为1/1时，下阶挡墙的地震土压力值最大。综合分析可知，墙高比为1/1时，临界台阶宽度在50 cm附近；当台阶宽度为20 cm时，上下阶墙体高度应有所区别，不宜均分，也不宜差距过大。研究成果可为双级加筋土挡墙工程设计中台阶宽度和上下阶墙高设置提供数据支撑。
- 双级加筋土挡墙 /
- 振动台试验 /
- 数值模拟 /
- 台阶宽度 /
- 墙高比
Abstract: In view of the unclear critical tier width and random height selection of upper and lower walls in two-tiered reinforced soil retaining walls under seismic loads, which hinders their application, a FLAC 3D model was built based on shaking table tests of two-tiered modular reinforced soil retaining walls. It analyzed face displacement, acceleration response, and seismic earth pressure distribution under different tier widths (10, 20, 30, 40, 50, 60 cm) and height ratios (3/7, 4/6, 1/1, 6/4, 7/3). Results revealed that facing displacement first decreased and then increased with tier width, hitting the minimum at 50 cm. The acceleration amplification factor rose nonlinearly with wall height, with attenuation in the upper wall at 40 and 60 cm widths. The lower wall's earth pressure was smallest at a 50 - cm tier width. The peak facing displacement was minimized when the height ratio was 4/6. The upper wall's maximum acceleration amplification occurred at a 6/4 ratio, while the lower wall's was at 1/1. The upper wall's seismic earth pressure was highest at 7/3, and the lower wall's at 1/1. Comprehensive analysis showed a critical tier width near 50 cm at a 1/1 ratio. At a 20 cm tier width, upper and lower wall heights should differ moderately. These findings offer data support for the design of two-tiered reinforced soil retaining walls, aiding in tier width and height configuration.
- Two-tiered reinforced soil retaining wall /
- Shaking table test /
- Numerical simulation /
- Offset distance /
- Wall height ratio

HTML全文

图 1 试验测试装置

Figure 1. Test device

下载: 全尺寸图片幻灯片

图 2 双级挡墙模型设计

Figure 2. Two-tiered retaining wall model design

下载: 全尺寸图片幻灯片

图 3 归一化5 Hz正弦波及傅氏谱

Figure 3. Normalized 5 Hz sine wave and Fourier spectrum

下载: 全尺寸图片幻灯片

图 4 双级数值模型

Figure 4. Two-tiered numerical model

下载: 全尺寸图片幻灯片

图 5 双级挡墙对比验证

Figure 5. Comparative verification of two-tiered retaining wall

下载: 全尺寸图片幻灯片

图 6 D=20 cm时各测点响应情况

Figure 6. The response of each measuring point when D = 20 cm

下载: 全尺寸图片幻灯片

图 7 不同台阶宽度动力响应对比

Figure 7. Comparison of dynamic response of different step widths

下载: 全尺寸图片幻灯片

图 8 不同分级墙高比动力响应对比

Figure 8. Comparison of dynamic response of different grading wall height ratio

下载: 全尺寸图片幻灯片

表 1 模型相似关系参数

Table 1. Model similarity relation parameters

变量	参数	相似关系	相似常数（原型/模型）
长度	L	${C_{\text{L}}}$	10
弹模	E	${C_{\text{E}}}$	1
密度	$\rho $	$ {C}_{\rho }=1 $	1
应力	$\sigma $	$ {C}_{\sigma }={C}_{E}=1 $	1
时间	$t$	${C_{\text{t}}} = C_{\text{L}}^{{\text{0}}{\text{.5}}}$	3.16
速度	$v$	${C_{\text{v}}} = C_{\text{L}}^{{\text{0}}{\text{.5}}}$	3.16
加速度	$a$	${C_{\text{a}}} = 1$	1
重力	$g$	${C_{\text{g}}} = 1$	1
频率	$\omega $	$ {C}_{\omega }={C}_{L}^{-0.5} $	0.316

下载: 导出CSV

表 2 实体单元材料参数

Table 2. Material parameters of solid element

组成部分	本构	密度/(kg·m⁻³)	体积模量/Pa	剪切模量/Pa	摩擦角/(°)	黏聚力/Pa
地基土	M-C	1820	6.667×10⁷	3.077×10⁷	41	1×10⁶
回填土	M-C	1820	6.667×10⁷	3.077×10⁷	41	1×10³
基础	弹性	2200	1.095×10¹⁰	1×10¹⁰	—	—
面板	弹性	2200	1.095×10¹⁰	1×10¹⁰	—	—
海绵垫	弹性	120	1.1×10⁶	8.35×10⁵	—	—

下载: 导出CSV

表 3 结构单元材料参数

Table 3. Material parameters of structural units

弹性模量/Pa	泊松比	密度/(kg·m⁻³)	厚度/m	耦合弹簧的切向刚度/Pa	耦合弹簧的粘聚力/Pa	耦合弹簧的摩擦角/(°)
2.6×10⁹	0.33	300	1×10⁻³	2×10⁷	1.48×10⁴	32

下载: 导出CSV

表 4 接触面单元计算参数

Table 4. Calculation parameters of contact surface element

接触面	法向刚度k_n	切向刚度k_s	界面摩擦角/(°)	界面黏聚力/Pa
面板-面板	1×10⁹	4×10⁷	36	5.8×10⁴
面板-基础	1×10⁹	4×10⁷	36	5.8 e×10⁴
面板-土体	1×10⁸	1×10⁶	25	2.5×10³

下载: 导出CSV

参考文献(23)

蔡博渊,蔡晓光,李思汉等,2024. 基于振动台试验的加筋土挡墙台阶效应分析. 岩石力学与工程学报,43(12):3108−3120.

Cai B. Y., Cai X. G., Li S. H., et al., 2024. Analysis of tiers effect of geosynthetic-reinforced soil retaining walls based on shaking table tests. Chinese Journal of Rock Mechanics and Engineering, 43(12): 3108−3120. (in Chinese)

蔡晓光,李思汉,黄鑫,2018a. 双级加筋土挡墙动力特性振动台试验. 中国公路学报,31(2):200−207.

Cai X. G., Li S. H., Huang X., 2018a. Shaking table tests on dynamic characteristics of two stage reinforced soil retaining wall. China Journal of Highway and Transport, 31(2): 200−207. (in Chinese)

蔡晓光,李思汉,黄鑫,2018b. 水平地震作用下双级加筋土挡墙格栅应变及破裂面分析. 岩土工程学报,40(8):1528−1534.

Cai X. G., Li S. H., Huang X., 2018b. Geogrid strain and failure surface of two-stage reinforced soil retaining wall under horizontal seismic loading. Chinese Journal of Geotechnical Engineering, 40(8): 1528−1534. (in Chinese)

蔡晓光,王学鹏,李思汉等,2023. 复合格宾土工格栅加筋土挡墙模型振动台试验. 振动工程学报,36(3):767−775.

Cai X. G., Wang X. P., Li S. H., et al., 2023. Shaking table test on the model of reinforced soil retaining wall with composite Gabion and geogrid. Journal of Vibration Engineering, 36(3): 767−775. (in Chinese)

蔡晓光,蔡博渊,李思汉等,2025. 台阶式加筋土挡墙地震行为演化特征对比分析. 振动工程学报,1−17. [2025-04-28]. https://link. cnki. net/urlid/32.1349. TB. 20250218.1555. 004. Cai X. G. ,Cai B. Y. ,Li S. H. ,et al. ,2025. Comparative analysis of seismic behavior evolution characteristics of tiered reinforced soil retaining walls. Journal of Vibration Engineering,1−17. [2025-04-28]. https://link.cnki.net/urlid/32.1349.TB.20250218.1555.004. (in Chinese).

雷胜友,2001. 台阶式加筋土挡墙的原型试验研究. 工程地质学报,9(1):44−50.

Lei S. Y., 2001. In-situ experimental study on stepped reinforced earth retaining wall. Journal of Engineering Geology, 9(1): 44−50. (in Chinese)

李思汉,蔡晓光,徐洪路等,2024. 水平地震作用下双级加筋土挡墙损伤识别研究. 振动工程学报,37(8):1423−1430.

Li S. H., Cai X. G., Xu H. L., et al., 2024. Damage identification of two-tiered reinforced soil retaining wall under horizontal seismic loading. Journal of Vibration Engineering, 37(8): 1423−1430. (in Chinese)

马星宇,陈相兆,张桂欣等,2025. 西藏定日6.8级地震震灾分析及启示. 震灾防御技术,20(1):13−23.

Ma X. Y., Chen X. Z., Zhang G. X., et al., 2025. Seismic disaster analysis and lessons learned from Dingri M6.8 earthquake in Xizang. Technology for Earthquake Disaster Prevention, 20(1): 13−23. (in Chinese)

王祥,徐林荣,2003. 双级土工格栅加筋土挡墙的测试分析. 岩土工程学报,25(2):220−224.

Wang X., Xu L. R., 2003. Test and analysis of two-step retaining wall reinforced by geogrid. Chinese Journal of Geotechnical Engineering, 25(2): 220−224. (in Chinese)

肖成志,高珊,李海谦等,2020. 均布荷载下台阶式加筋土挡墙性能的试验分析. 工程地质学报,28(6):1359−1367.

Xiao C. Z., Gao S., Li H. Q., et al., 2020. Experimental study on performance of multi-tiered geogrid reinforced soil retaining wall under uniform static load. Journal of Engineering Geology, 28(6): 1359−1367. (in Chinese)

肖成志,李海谦,高珊等,2021a. 循环荷载下台阶式加筋土挡墙力学与变形性能的试验研究. 岩石力学与工程学报,40(4):802−813.

Xiao C. Z., Li H. Q., Gao S., et al., 2021a. Experimental study on mechanical and deformation performances of geogrids-reinforced soil retaining walls under cyclic loading. Chinese Journal of Rock Mechanics and Engineering, 40(4): 802−813. (in Chinese)

肖成志,李海谦,高珊等,2021b. 交通荷载下台阶式加筋土挡墙动力响应的试验研究. 岩土工程学报,43(10):1789−1797.

Xiao C. Z., Li H. Q., Gao S., et al., 2021b. Dynamic response of tiered geogrid-reinforced soil retaining walls under traffic loading. Chinese Journal of Geotechnical Engineering, 43(10): 1789−1797. (in Chinese)

杨广庆,蔡英,2000. 多级台阶式加筋土挡土墙试验研究. 岩土工程学报,22(2):254−257.

Yang G. Q., Cai Y., 2000. Study on the multi-steps reinforced earth retaining wall. Chinese Journal of Geotechnical Engineering, 22(2): 254−257. (in Chinese)

杨广庆,刘伟超,刘华北等,2018. 台阶式加筋土挡墙水平位移模式研究. 岩石力学与工程学报,37(S1):3652−3658.

Yang G. Q., Liu W. C., Liu H. B., et al., 2018. Horizontal displacement modes of tiered geosynthetic reinforced soil retaining wall. Chinese Journal of Rock Mechanics and Engineering, 37(S1): 3652−3658. (in Chinese)

张黎,徐晓攀,蔡晓光等,2022. 刚/柔组合墙面加筋土挡墙动力响应数值分析. 防灾科技学院学报,24(1):1−12.

Zhang L., Xu X. P., Cai X. G., et al., 2022. Numerical simulation analysis of seismic dynamic response of reinforced soil retaining walls with rigid/flexible facing. Journal of Institute of Disaster Prevention, 24(1): 1−12. (in Chinese)

周中红,陈文凯,孙艳萍,2024. 2000−2021年甘肃省地震灾害人员伤亡特征. 震灾防御技术,19(2):296−305.

Zhou Z. H., Chen W. K., Sun Y. P., 2024. Characteristics of earthquake casualties in Gansu province from 2000 to 2021. Technology for Earthquake Disaster Prevention, 19(2): 296−305. (in Chinese)

Cai B. Y., Cai X. G., Li S. H., et al., 2025. Experimental study of shaking table for reinforced soil retaining walls: Analysis of tiered configuration effects. Soil Dynamics and Earthquake Engineering, 188: 109076. doi: 10.1016/j.soildyn.2024.109076

Gao S., Xiao C. Z., Han J., et al., 2022. Lateral displacements of geosynthetic-reinforced soil walls in a tiered configuration. Journal of Geotechnical and Geoenvironmental Engineering, 148(9): 04022066. doi: 10.1061/(ASCE)GT.1943-5606.0002853

Iai S., 1989. Similitude for shaking table tests on soil-structure-fluid model in 1g gravitational field. Soils and Foundations, 29(1): 105−118. doi: 10.3208/sandf1972.29.105

Li S. H., Cai X. G., Jing L. P., et al., 2021. Lateral displacement control of modular-block reinforced soil retaining walls under horizontal seismic loading. Soil Dynamics and Earthquake Engineering, 141: 106485. doi: 10.1016/j.soildyn.2020.106485

Liu H. , 2011. Comparing the seismic responses of single- and multi-tiered geosynthetic reinforced soil walls. In: Han J. , Alzamora D. A. , eds. , Geo-Frontiers 2011: Advances in Geotechnical Engineering. Red Hook: Curran Associates, Inc. , 3478−3486.

Safaee A. M., Mahboubi A., Noorzad A., 2023. Seismic behavior of tiered geogrid reinforced soil (GRS) using treated backfill soil. Geosynthetics International, 30(2): 200−224. doi: 10.1680/jgein.21.00060

Yoo C., Jang Y. S., Park I. J., 2011. Internal stability of geosynthetic-reinforced soil walls in tiered configuration. Geosynthetics International, 18(2): 74−83. doi: 10.1680/gein.2011.18.2.74
