Research on Seismic Response Characteristics of High-Speed Railway Hub Station Structure System Considering Pile-Soil Interaction
-
摘要: 高铁枢纽车站作为关键交通基础设施，保证其抗震安全具有重要意义。以常德高铁枢纽车站结构为研究对象，选取代表性的强震记录作为基岩地震动，考虑场地工程地质特性、土体非线性和桩-土动力相互作用，采用有限元方法对高铁枢纽车站结构三维体系进行非线性地震反应分析。结果表明：考虑桩-土相互作用的高铁枢纽车站结构体系整体上呈现“上柔下刚”的特点，自振频率相比刚性地基假定的车站结构体系降低；在3种强地震动作用下，场地非线性地震效应显著，地表加速度显著放大，场地土的地震响应随着埋深增大逐渐减小；桩-土之间相互作用与场地非线性地震效应相关，两者相互作用的强度随着地震动强度的增大而增大；三种地震波中以Kobe波的卓越频率与车站结构体系自振频率最为接近，El Centro波次之；屋盖结构的存在导致车站框架结构地震响应随高度逐渐放大，且屋盖结构与下部框架结构连接处的地震响应放大最大，因此导致车站结构顶层的最大层间位移角大于底层的最大层间位移角。Abstract: As a key transportation infrastructure, the high-speed railway hub station is of great significance to ensure its seismic safety. Taking the structure of Changde high-speed railway hub station as the research object, the representative strong earthquake records are selected as the seismic bedrock motion. Considering the engineering geological characteristics of the site, soil nonlinearity, and pile-soil dynamic interaction, the finite element method is used to analyze the nonlinear earthquake response of the three-dimensional system of the high-speed railway station structure. The results show that: the structural system of a high-speed railway hub station considering pile-soil interaction presents the characteristics of 'soft-upper-rigid-down' as a whole, and the natural frequency is lower than that of the station structural system with rigid foundation assumption; Under the action of three kinds of strong ground motions, the nonlinear seismic effect of the site is significant, the surface acceleration is significantly enlarged, and the seismic response of the site soil gradually decreases with the increases of buried depth; The interaction between piles and soil is related to the nonlinear seismic effect of the site, and the intensity of the interaction between the two increases with the increases of the ground motion intensity; Among the three kinds of seismic waves, the predominant frequency of Kobe wave is the closest to the natural frequency of the station structure system, followed by El Centro wave; The existence of the roof structure leads to the gradual amplification of the seismic response of the station frame structure with height, and the seismic response amplification at the connection between the roof structure and the base frame structure is the largest. Therefore, the maximum inter-story displacement angle of the top layer of the station structure is greater than that of the bottom layer.
-
图 1 基岩输入地震动的加速度时程及其傅里叶谱
Figure 1. Acceleration time history and Fourier spectrum of earthquake motion input from bedrock
图 2 考虑桩-土相互作用的高铁枢纽车站结构体系有限元模型示意图及其局部细节图
Figure 2. Schematic diagram of finite element model of high-speed railway hub station structure system considering pile-soil interaction and its partial detail diagram
图 4 结构模型前6阶自振频率对比
Figure 4. Comparison of the first 6 order natural vibration frequencies of structural models
图 5 不同PBA的地震动作用下场地土沿深度的地震响应
Figure 5. Seismic responses of site soil along depth under the action of earthquake vibration with different PBA
图 6 Kobe波作用下4个角桩和边桩的地震响应
Figure 6. Seismic responses of four corner piles and side piles under Kobe wave action
图 7 不同PBA的地震动作用下框架结构地震响应沿结构高度变化
Figure 7. Seismic responses of the frame structure varies with the height of the structure under the action of earthquake motion with different PBA
图 8 Kobe波和El Centro波作用下各层4个角柱的位移
Figure 8. Displacement of four corner columns in each layer under the action of Kobe wave and El Centro wave
图 9 两种地震动作用下车站结构最大层间位移角
Figure 9. Maximum Story-drift of station structure under the action of two kinds of earthquake motions
表 1 混凝土和钢材的本构模型参数
Table 1. Constitutive model parameters of concrete and steel
组分 密度/(kg·m−3) 抗拉强度/MPa 抗压强度/MPa 弹性模量/GPa 泊松比 C40混凝土 2500 2.39 26.8 32.5 0.2 钢材 7900 650 420 210 0.3
下载: 导出CSV
表 2 场地土的本构模型参数
Table 2. Constitutive model parameters of site soil
土层结构 土体类别 深度/m 密度/(kg·m−3) 剪切波速/(m·s−1) 泊松比 A B 参考剪应变 小应变阻尼比 表层 回填土 2.6 1900 176 0.47 1.05 0.42 0.00031 0.025 中层 黏土 14.6 1950 236 0.45 1.06 0.44 0.00053 0.024 中下层 粉砂 33.6 2000 289 0.43 1.07 0.46 0.00082 0.022 下层 砂土 50.6 2030 469 0.43 1.10 0.47 0.00092 0.020 底层 基岩 55.6 2240 641 0.40 1.12 0.43 0.0012 0.018
下载: 导出CSV
表 3 横截面跨中杆件节点相对位移响应峰值
Table 3. Relative displacement response peak values of mid-span member joints in cross section
方向 结构 PBA=0.1 g PBA=0.2 g Kobe Taft El Centro Kobe Taft El Centro 横向 特征系数/% 2.72 5.86 25.29 3.29 5.48 18.46 纵向 特征系数/% 243 140.99 166.80 315 139.70 165.86 竖向 特征系数/% 220.88 743.13 570.43 146.42 639.52 411.56
下载: 导出CSV
表 4 纵截面跨中杆件节点相对位移响应峰值
Table 4. Relative displacement response peak values of mid-span member joints in longitudinal section
方向 结构 PBA=0.1 g PBA=0.2 g Kobe Taft El Centro Kobe Taft El Centro 横向 特征系数/% 2.66 5.52 24.39 3.25 5.47 18.16 纵向 特征系数/% 1458.12 1221.78 1568.15 2025.69 1175.47 1519 竖向 特征系数/% 2054.62 5018.46 4419.73 1199 4326.49 3164.91
下载: 导出CSV
-
丁阳, 石运东, 宗亮等, 2023. 枢纽车站结构地震响应特征. 工程力学, 40(4): 1−11.Ding Y., Shi Y. D., Zong L., et al., 2023. Research on seismic response characteristics of hub structures. Engineering Mechanics, 40(4): 1−11. (in Chinese) 姜守芳, 李会军, 龙婷婷, 2022. 考虑节点偏差、杆件缺陷与偏心的单层三向柱面网壳稳定性研究. 工程力学, 39(2): 178−188.Jiang S. F., Li H. J., Long T. T., 2022. Stability of single-layer three-way reticulated barrel vaults considering global geometric imperfection, member imperfection and eccentricity. Engineering Mechanics, 39(2): 178−188. (in Chinese) 刘河江, 邓华, 2012. 罕遇地震下双层球面网壳的弹塑性动力响应分析. 振动与冲击, 31(24): 161−167, 176.Liu H. J., Deng H., 2012. Elasto-plastic dynamic response analysis for double-layer spherical reticulated shells under rare earthquake. Journal of Vibration and Shock, 31(24): 161−167,176. (in Chinese) 宋志文, 2014. 新建沈阳南站中央站房轨道层结构设计研究. 铁道工程学报, 31(6): 81−86.Song Z. W., 2014. Research on the structure design for the central station track level of newly-built Shenyang South Railway Station. Journal of Railway Engineering Society, 31(6): 81−86. (in Chinese) 苏亮, 董石麟, 2007. 竖向多点输入下两种典型空间结构的抗震分析. 工程力学, 24(2): 85−90.Su L., Dong S. L., 2007. Seismic analysis of two typical spatal structures under multi-support vertical excitations. Engineering Mechanics, 24(2): 85−90. (in Chinese) 孙宝睿, 2021. “站桥合一”式高铁车站结构振动台试验研究. 徐州: 中国矿业大学.Sun B. R. , 2021. Shaking table test of "integrated station-bridge" high-speed railway station structure. Xuzhou: China University of Mining and Technology. (in Chinese) 孙梦涵, 范峰, 支旭东等, 2014. 考虑下部柱支承四角锥网架结构动力响应分析. 土木工程学报, 47(12): 9−15.Sun M. H., Fan F., Zhi X. D., et al., 2014. Analysis on dynamic response of quadrangular pyramid grid structure with supporting columns. China Civil Engineering Journal, 47(12): 9−15. (in Chinese) 王刚, 张建民, 魏星, 2011. 可液化土层中地下车站的地震反应分析. 岩土工程学报, 33(10): 1623−1627.Wang G., Zhang J. M., Wei X., 2011. Seismic response analysis of a subway station in liquefiable soil. Chinese Journal of Geotechnical Engineering, 33(10): 1623−1627. (in Chinese) 王国波, 郝朋飞, 孙富学, 2020. 地铁车站结构端部效应影响范围研究. 岩土工程学报, 42(8): 1435−1445.Wang G. B., Hao P. F., Sun F. X., 2020. Spatial influence scope of end wall of metro station structures. Chinese Journal of Geotechnical Engineering, 42(8): 1435−1445. (in Chinese) 王彦臻, 赵丁凤, 陈国兴等, 2021. 一维场地地震反应非线性有效应力分析法及其验证. 岩土工程学报, 43(3): 502−510.Wang Y. Z., Zhao D. F., Chen G. X., et al., 2021. A new nonlinear effective stress method for one-dimensional seismic site response analysis and its validation. Chinese Journal of Geotechnical Engineering, 43(3): 502−510. (in Chinese) 叶永平, 2024. 高铁车站结构动力特性及抗震性能分析. 铁道建筑技术, (10): 188−192.Ye Y. P., 2024. Analysis of dynamic characteristics and seismic performance of high-speed railway station structure. Railway Construction Technology, (10): 188−192. (in Chinese) 张兰兰, 徐俊豪, 张营营等, 2023. 基于IDA的“站桥合一”式高铁车站结构地震易损性分析. 工程抗震与加固改造, 45(6): 86−94.Zhang L. L., Xu J. H., Zhang Y. Y., et al., 2023. Seismic vulnerability analysis of "integrated station-bridge" high-speed railway station structure based on IDA. Earthquake Resistant Engineering and Retrofitting, 45(6): 86−94. (in Chinese) 章小龙, 李小军, 陈国兴等, 2016. 黏弹性人工边界等效荷载计算的改进方法. 力学学报, 48(5): 1126−1135.Zhang X. L., Li X. J., Chen G. X., et al., 2016. An improved method of the calculation of equivalent nodal forces in viscous-elastic artificial boundary. Chinese Journal of Theoretical and Applied Mechanics, 48(5): 1126−1135. (in Chinese) 赵丁凤, 阮滨, 陈国兴等, 2017. 基于Davidenkov骨架曲线模型的修正不规则加卸载准则与等效剪应变算法及其验证. 岩土工程学报, 39(5): 888−895.Zhao D. F., Ruan B., Chen G. X., et al., 2017. Validation of modified irregular loading-unloading rules based on Davidenkov skeleton curve and its equivalent shear strain algorithm implemented in ABAQUS. Chinese Journal of Geotechnical Engineering, 39(5): 888−895. (in Chinese) 赵凯, 夏高旭, 王彦臻等, 2022. 土-地下结构相互作用的三维弱耦合有效应力分析法. 岩土工程学报, 44(5): 861−869.Zhao K., Xia G. X., Wang Y. Z., et al., 2022. Three-dimensional loosely coupled effective stress method for seismic soil-structure interactions. Chinese Journal of Geotechnical Engineering, 44(5): 861−869. (in Chinese) 朱升冬, 陈国兴, 蒋鹏程等, 2021. 松软场地上桩筏基础AP1000核岛结构的三维非线性地震反应特性. 工程力学, 38(1): 129−142.Zhu S. D., Chen G. X., Jiang P. C., et al., 2021. 3D nonlinear response characteristics of the pile-raft-supported AP1000 nuclear island building in soft deposits subjected to strong ground motions. Engineering Mechanics, 38(1): 129−142. (in Chinese) 朱升冬, 陈国兴, 陈炜昀等, 2023a. 土的次非线性对桩基核岛结构三维地震反应的影响. 岩土力学, 44(5): 1501−1511.Zhu S. D., Chen G. X., Chen W. Y., et al., 2023a. Influence of soil secondary nonlinearity on 3D seismic responses of a pile-founded nuclear island structure. Rock and Soil Mechanics, 44(5): 1501−1511. (in Chinese) 朱升冬, 陈国兴, 陈炜昀等, 2023b. 考虑土体非线性的核岛结构桩基础三维地震反应特性. 土木工程学报, 56(11): 124−136.Zhu S. D., Chen G. X., Chen W. Y., et al., 2023b. 3D seismic response characteristics of piles of a nuclear island building considering nonlinearity of soil. China Civil Engineering Journal, 56(11): 124−136. (in Chinese) 邹德高, 徐斌, 孔宪京, 2011. 瑞利阻尼系数确定方法对高土石坝地震反应的影响研究. 岩土力学, 32(3): 797−803. doi: 10.3969/j.issn.1000-7598.2011.03.026Zou D. G., Xu B., Kong X. J., 2011. Study of influence of different methods for calculating Rayleigh damping coefficient on high earth-rock dam seismic response. Rock and Soil Mechanics, 32(3): 797−803. (in Chinese) doi: 10.3969/j.issn.1000-7598.2011.03.026 Chen G. X., Chen S., Qi C. Z., et al., 2015a. Shaking table tests on a three-arch type subway station structure in a liquefiable soil. Bulletin of Earthquake Engineering, 13(6): 1675−1701. doi: 10.1007/s10518-014-9675-0 Chen G. X., Chen S., Zuo X., et al., 2015b. Shaking-table tests and numerical simulations on a subway structure in soft soil. Soil Dynamics and Earthquake Engineering, 76: 13−28. doi: 10.1016/j.soildyn.2014.12.012 Chen G. X., Ruan B., Zhao K., et al., 2020. Nonlinear response characteristics of undersea shield tunnel subjected to strong earthquake motions. Journal of Earthquake Engineering, 24(3): 351−380. doi: 10.1080/13632469.2018.1453416 Chen G. X., Wang Y. Z., Zhao D. F., et al., 2021. A new effective stress method for nonlinear site response analyses. Earthquake Engineering & Structural Dynamics, 50(6): 1595−1611. doi: 10.1002/eqe.3414 Chen G. X., Zhu S. D., Chen W. Y., et al., 2022. 3D seismic response characteristics of a pile-mat-founded AP1000 nuclear-island building considering nonlinear hysteretic behavior of soil. Bulletin of Earthquake Engineering, 20(13): 7077−7106. doi: 10.1007/s10518-022-01483-z Hudson M. , Idriss I. M. , Beikae M. , 1994. User’s manual for QUAD4m: A computer program to evaluate the seismic response of soil structures using finite element procedures incorporating a compliant base. Berkeley: University of California. Kuhlemeyer R. L., Lysmer. J., 1973. Finite element method accuracy for wave propagation problems. Journal of the Soil Mechanics and Foundations Division, 99(5): 421−427. doi: 10.1201/9781315372099-13 Nakazawa S., Kato S., Yagi Y., 2012. Evaluation of seismic damage of single layer lattice dome supported by ductile braces. Journal of Structural and Construction Engineering, 77(674): 593−601. doi: 10.3130/aijs.77.593 Nakazawa S., Yanagisawa T., Kato S., 2014. Seismic loads for single layer reticular domes and seismic performance evaluation. Journal of Structural and Construction Engineering, 79(703): 1287−1297. Yang J., Zhuang H. Y., Wang W., et al., 2021. Seismic performance and effective isolation of a large multilayered underground subway station. Soil Dynamics and Earthquake Engineering, 142: 106560. doi: 10.1016/j.soildyn.2020.106560 Zhuang H. Y., Hu Z. H., Wang X. J., et al., 2015. Seismic responses of a large underground structure in liquefied soils by FEM numerical modelling. Bulletin of Earthquake Engineering, 13(12): 3645−3668. doi: 10.1007/s10518-015-9790-6 Zhuang H. Y., Ren J. W., Miao Y., et al., 2021. Seismic performance levels of a large underground subway station in different soil foundations. Journal of Earthquake Engineering, 25(14): 2808−2833. doi: 10.1080/13632469.2019.1651423 Zhuang H. Y., Wang W., Jin L. G., et al., 2022. Seismic performance of two-story subway station structures with different isolating systems. Earthquake Research Advances, 2(4): 100155. doi: 10.1016/j.eqrea.2022.100155 Zhuang H. Y., Zhao D. F., Chen G. X., et al., 2023. Three-dimensional numerical investigation on seismic response of subway station in liquefied soil by the loosely coupled effective stress model. Journal of Earthquake Engineering, 27(13): 3607−3631. doi: 10.1080/13632469.2022.2141371 -
