Study on Typical Earthquake Hazards and Seismic Vulnerability of Residential Houses in Hubei Province
-
摘要: 为获得符合湖北震损情况及民居建筑特点的房屋震害矩阵，基于8次湖北省历史地震调查资料及十堰地区房屋现场调查结果，以乡镇及农村民居为研究对象，系统分析了砖混结构、砖木结构和土木结构3种典型民居的结构特点与震害特征，采用Beta概率密度函数对高烈度区震害矩阵数据进行补充，构建了湖北民居地震易损性矩阵，通过与规范中的地震烈度表进行对比分析，验证了地震易损性矩阵的可靠性。研究结果为湖北地区乡镇及农村民居建筑的抗震性能评估及震害计算提供了科学依据和有效参考。Abstract: In order to obtain the seismic damage matrix of houses in line with the seismic damage situation and the characteristics of residential buildings in Hubei Province, this paper systematically analyzes the structural characteristics and seismic damage characteristics of three typical residential buildings, namely brick-concrete structure, brick-wood structure and civil engineering structure, based on the historical seismic survey data of 8 historical earthquakes in Hubei Province and the results of housing field investigation in Shiyan area, taking township and rural residential buildings as the research object, and uses the Beta probability density function to supplement the seismic damage matrix data in the high intensity area, and constructs the seismic vulnerability matrix of Hubei residential buildings. The reliability of the seismic vulnerability matrix is verified by comparing it with the seismic intensity table in the specification. The research results provide a scientific basis and an effective reference for the seismic performance evaluation and seismic damage calculation of township and rural residential buildings in Hubei Province.
-
图 1 历次地震及现场调查房屋比例变化示意
Figure 1. Schematic diagram of the change in the proportion of houses in previous earthquakes and field surveys
图 5 土木结构震害特征
Figure 5. Characteristics of seismic damage of civil engineering structures
表 1 历次地震建筑破坏比统计数据
Table 1. Statistics on building damage ratios from previous earthquakes
地震事件 地震烈度 民居类别 破坏程度/% 基本完好 轻微破坏 中等破坏 严重破坏 毁坏 2005年11月26日九江-瑞昌5.7级地震 VII 砖混结构 49.60 12.40 35.00 2.40 0.60 VI 砖混结构 65.20 16.30 18.00 0.50 0.00 2006年10月27日随州三里岗4.2级地震 VI 砖混结构 67.36 26.47 6.17 0.00 0.00 砖木结构 57.04 34.60 7.26 1.10 0.00 2008年03月24日竹山县4.1级地震 VI 砖混结构 85.90 14.10 0.00 0.00 0.00 土木结构 100.00 0.00 0.00 砖木结构 80.00 20.00 0.00 0.00 0.00 2008年11月22日屈原镇4.1级地震 VI 砖混结构 84.80 15.20 0.00 0.00 0.00 土木结构 87.00 13.00 0.00 2013年12月16日巴东5.1级地震 VI 砖混结构 77.29 21.35 1.36 0.00 0.00 土木结构 95.62 3.72 0.66 VII 砖混结构 53.06 26.64 15.16 4.48 0.66 土木结构 72.74 17.44 9.82 2014年03月30日秭归4.5级地震 VI 砖混结构 57.42 26.93 12.10 3.55 0.00 土木结构 83.20 16.80 0.00 2017年06月16日秭归-巴东交界4.3级地震 VI 砖混结构 70.85 19.43 9.21 0.51 0.00 土木结构 80.26 16.15 3.59 2019年12月16日应城4.9级地震 VII 砖混结构 20.00 53.30 26.70 0.00 0.00 VI 砖混结构 80.90 13.40 5.70 0.00 0.00 土木结构 83.30 16.70 0.00 注：土木结构与砖木、砖混结构破坏等级分类不同，表中土木结构分类依次对应基本完好、破坏、毁坏3个等级。
下载: 导出CSV
表 2 湖北地区民居经验易损性矩阵（单位：%）
Table 2. Empirical fragility matrix of dwellings in Hubei Province（Unit: %）
民居类别 地震烈度 基本完好 轻微破坏 中等破坏 严重破坏 毁坏 砖混结构 VI 73.71 19.15 6.57 0.57 0.00 VII 40.89 30.78 25.62 2.29 0.42 砖木结构 VI 68.52 27.30 3.63 0.55 0.00 土木结构 VI 89.22 9.93 0.85 注：土木结构与砖木、砖混结构破坏等级分类不同，表中土木结构分类依次对应基本完好、破坏、毁坏3个等级。
下载: 导出CSV
表 3 不同强度震害指数的期望值与方差
Table 3. Expected values and variances of seismic damage indices of different intensities
结构类型 地震烈度 标准震害矩阵 实际震害矩阵 期望 方差 期望 方差 砖混结构 VI 0.1209 0.0157 0.1071 0.0163 VII 0.2243 0.0396 0.2108 0.0386 VIII 0.3257 0.0659 0.3122 0.0649 IX 0.5381 0.0792 0.5246 0.0782 X 0.7821 0.0593 0.7686 0.0583 砖木结构 VI 0.1261 0.0162 0.1081 0.0203 VII 0.2253 0.0305 0.2073 0.0346 VIII 0.4365 0.0665 0.4185 0.0706 IX 0.6533 0.0509 0.6353 0.0550 X 0.8215 0.0301 0.8035 0.0342 土木结构 VI 0.1565 0.0238 0.0835 0.0183 VII 0.3408 0.0668 0.2678 0.0613 VIII 0.5550 0.0756 0.4820 0.0701 IX 0.7438 0.0540 0.6708 0.0485 X 0.8925 0.0137 0.8195 0.0082
下载: 导出CSV
表 4 高烈度震害指数概率密度函数的α及β值
Table 4. The α and β values of the probability density function of the high-intensity seismic damage index
结构类型 地震烈度 期望 方差 α β 砖混结构 VIII 0.3163 0.0567 0.7208 1.5879 IX 0.5287 0.0700 1.1485 1.0407 X 0.7727 0.0501 1.5761 0.4745 砖木结构 VII 0.2073 0.0346 0.7772 2.9721 VIII 0.4185 0.0706 1.0241 1.4229 IX 0.6353 0.0550 2.0410 1.1716 X 0.8035 0.0342 2.9059 0.7107 土木结构 VII 0.2815 0.0615 0.5889 1.6099 VIII 0.4957 0.0703 1.2347 1.3270 IX 0.6845 0.0487 2.3835 1.1697 X 0.8332 0.0084 13.9635 3.0755
下载: 导出CSV
表 5 湖北地区民居综合易损性矩阵（单位：%）
Table 5. Comprehensive fragility matrix of residential buildings in Hubei Province（Unit：%）
结构类型 地震烈度 基本完好 轻微破坏 中等破坏 严重破坏 毁坏 砖混结构 VI 73.71 19.15 6.57 0.57 0.00 VII 40.89 30.78 25.62 2.29 0.42 VIII 26.71 16.15 23.77 23.13 10.24 IX 3.28 13.10 19.72 31.80 32.10 X 1.07 2.24 7.43 38.89 50.37 砖木结构 VI 68.52 27.30 3.63 0.55 0.00 VII 37.49 21.28 25.12 14.22 1.89 VIII 13.24 13.06 24.45 30.76 18.49 IX 1.15 3.51 13.95 36.27 45.12 X 0.07 0.47 3.75 20.36 75.35 土木结构 VI 89.22 9.93 0.85 VII 44.73 29.21 26.06 VIII 27.91 30.55 41.54 IX 0.53 28.14 71.33 X 0.00 0.74 99.26 注：土木结构与砖木、砖混结构破坏等级分类不同，表中土木结构分类依次对应基本完好、破坏、毁坏3个等级。
下载: 导出CSV
表 6 湖北民居平均震害指数与烈度表规定范围对比
Table 6. Comparison between the average seismic damage index of residential buildings in Hubei province and the specified range of the intensity table
结构类型 平均震害指数 地震烈度 VI VII VIII IX X 砖混结构 范围值 0.00-0.11 0.09-0.27 0.25-0.50 0.48-0.69 0.67-0.91 计算值 0.07 0.18 0.39 0.65 0.81 砖木结构 范围值 0.02-0.17 0.15-0.44 0.42-0.62 0.60-0.90 0.88-1.00 计算值 0.07 0.26 0.52 0.77 0.91 土木结构 范围值 0.02-0.17 0.15-0.44 0.42-0.62 0.60-0.90 0.88-1.00 计算值 0.04 0.32 0.46 0.70 0.88
下载: 导出CSV
-
胡少卿, 孙柏涛, 王东明等, 2007. 经验震害矩阵的完善方法研究. 地震工程与工程振动, 27(6): 46−50.Hu S. Q., Sun B. T., Wang D. M., et al., 2007. Approach to making empirical earthquake damage matrix. Journal of Earthquake Engineering and Engineering Vibration, 27(6): 46−50. (in Chinese) 黄文涛, 熊永良, 张莹等, 2022. 川南地区民居建筑地震易损性研究. 华北地震科学, 40(4): 40−49.Huang W. T., Xiong Y. L., Zhang Y., et al., 2022. Research on seismic vulnerability of residential buildings in southern Sichuan. North China Earthquake Sciences, 40(4): 40−49. (in Chinese) 李碧雄, 王甜恬, 赵开鹏等, 2021. 传统藏式民居的典型震害及易损性研究. 建筑结构学报, 42(S1): 165−173.Li B. X., Wang T. T., Zhao K. P., et al., 2021. Typical earthquake damage of traditional Tibetan dwellings and its vulnerability. Journal of Building Structures, 42(S1): 165−173. (in Chinese) 李书进, 毛羚, 陶礼龙等, 2010. 湖北农村民居抗震性能调查与分析. 震灾防御技术, 5(1): 116−124.Li S. J., Mao L., Tao L. L., et al., 2010. Seismic performance investigation and analysis of rural buildings in Hubei Province. Technology for Earthquake Disaster Prevention, 5(1): 116−124. (in Chinese) 李垠, 郑水明, 张萍, 2024. 湖北农居建筑现状调查及抗震性能分析−−以黄梅县蔡山镇为例. 华南地震, 44(1): 43−51.Li Y., Zheng S. M., Zhang P., 2024. Current situation investigation and seismic performance analysis of rural residential buildings in Hubei Province−−Taking Caishan Town, Huangmei County as an example. South China Journal of Seismology, 44(1): 43−51. (in Chinese) 刘晓丹, 刘志辉, 魏艳旭, 2024. 基于风险普查的邢台村镇地区房屋现状调查与震害预测. 震灾防御技术, 19(4): 716−725.Liu X. D., Liu Z. H., Wei Y. X., 2024. Buildings status investigation and earthquake damage prediction in Xingtai Village based on risk survey. Technology for Earthquake Disaster Prevention, 19(4): 716−725. (in Chinese) 罗杰, 2009. 九江瑞昌5.7级地震主要结构类型房屋破坏成因分析. 华南地震, 29(1): 115−121.Luo J., 2009. Analysis on damages of different types of building structures in the MS5.7 Jiujiang Ruichang earthquake. South China Journal of Seismology, 29(1): 115−121. (in Chinese) 毛羚, 2009. 湖北农村民居抗震性能调查与震害预测研究. 武汉: 武汉理工大学. Mao L. , 2009. Seismic performance investigation and seismic damage prediction of rural buildings in Hubei Province. Wuhan: Wuhan University of Technology. (in Chinese). 孙柏涛, 陈洪富, 闫培雷等, 2014. 南北地震带房屋建筑抗震能力分区特征研究−−以四川省为例. 土木工程学报, 47(S1): 6−10.Sun B. T., Chen H. F., Yan P. L., et al., 2014. Research on zoned characteristics of building seismic capacity along North South seismic belt-take Sichuan province as an example. China Civil Engineering Journal, 47(S1): 6−10. (in Chinese) 王郁, 刘爱文, 李祥秀等, 2021. 基于震害资料的西藏地区典型民居易损性分析. 震灾防御技术, 16(2): 245−252.Wang Y., Liu A. W., Li X. X., et al., 2021. Vulnerability analysis of typical dwellings in Tibet based on earthquake damage data. Technology for Earthquake Disaster Prevention, 16(2): 245−252. (in Chinese) 邢灿飞, 秦小军, 2006. 九江-瑞昌5.7级地震灾害损失快速评估(湖北). 大地测量与地球动力学, 26(4): 107−111.Xing C. F., Qin X. J., 2006. Fast evaluation of earthquake disaster loss (inside Hubei Province) for Jiujiang-Ruichang MS 5.7 earthquake. Journal of Geodesy and Geodynamics, 26(4): 107−111. (in Chinese) 尹之潜, 1996. 结构易损性分类和未来地震灾害估计. 中国地震, 12(1): 49−55.Yin Z. Q., 1996. Classification of structure vulnerability and evaluating earthquake damage from future earthquake. Earthquake Research in China, 12(1): 49−55. (in Chinese) 袁丽, 王秋良, 李井冈等, 2014. 湖北农村民居震害特征及防御对策. 防灾减灾工程学报, 34(3): 395−400.Yuan L., Wang Q. L., Li J. G., et al., 2014. Earthquake damage characteristics of rural residences in Hubei Province and its defense countermeasure. Journal of Disaster Prevention and Mitigation Engineering, 34(3): 395−400. (in Chinese) 张莹, 郭红梅, 尹文刚等, 2024. 川南地区砖混结构房屋典型震害及地震易损性研究. 地震工程学报, 46(2): 358−368.Zhang Y., Guo H. M., Yin W. G., et al., 2024. Typical damage and seismic vulnerability of brick-concrete structural buildings in south Sichuan. China Earthquake Engineering Journal, 46(2): 358−368. (in Chinese) -
