Random Seismic and Reliability Analysis of Bridges Based on an Improved Frozen Soil-Pile-Cap Interaction Model
-
摘要: 在季节冻土区，桥梁结构的抗震设计面临复杂挑战，主要原因在于地震动的不确定性以及冻融效应对土体-桩-桥梁相互作用的影响。本文改进并验证了现有的桩-土相互作用模型，并基于该模型分析了在Ⅷ度随机地震作用下桩基础公路桥梁的动力响应与抗震可靠度。采用概率密度演化方法和等价极值分布理论，选取水平相对位移转角作为桥墩动力性能评价指标，对100次随机地震样本进行结构动力响应分析。结果表明，不同地震时程下桥墩的水平位移差异显著，1号桥墩的位移大于2号桥墩，表明1号桥墩更易受到地震损害，这主要是由于两者的结构形式和几何尺寸不同。此外，季节冻土层对桥梁的位移响应影响较大，通常能减小桥墩的水平位移，但在特定情况下则可能增加位移。2号桥墩在随机地震作用下表现出较小的位移转角，抗震性能优于1号桥墩。抗震可靠度分析结果表明，季节冻土层对桥梁的抗震性能具有积极作用，为季节冻土区桩基础公路桥梁的抗震设计提供了理论依据。Abstract: The seismic design of bridge structures in seasonal frozen soil regions faces significant challenges, primarily due to the uncertainty of ground motion, and the influence of soil freeze-thaw effects on soil-pile-bridge interaction. This study improves and validates an existing pile-soil interaction model, and then, based on this model, analyzes the dynamic response and seismic reliability of pile-supported highway bridges under random earthquakes with an intensity of VIII. Using the probability density evolution method and equivalent extreme value distribution theory, the horizontal relative displacement angle is selected as the dynamic performance evaluation index for the bridge piers. The bridge dynamic responses to 100 random seismic samples are analyzed. The results show that Pier No. 1 has a larger horizontal displacement than Pier No. 2, indicating that Pier No. 1 is more susceptible to earthquake damage. Furthermore, the seasonal frozen soil layer significantly impacts the bridge's displacement response, typically reducing the horizontal displacement of the bridge pier, though it may increase the displacement under certain conditions. Pier No. 2 demonstrates smaller displacement under random earthquake actions, indicating better seismic performance compared to that of Pier No. 1. Seismic reliability analysis reveals that the seasonal frozen soil layer positively affects the seismic performance of the bridge, offering a theoretical foundation for the seismic design of pile-supported highway bridges in seasonal frozen soil regions.
-
图 9 原型桥梁三维有限元示意图
Figure 9. Three-dimensional finite element diagram of a prototype bridge
图 11 100条代表性时程样本下桥墩水平相对位移极值
Figure 11. Peak value of pier relative horizontal displacement under 100 representative time-history samples
图 12 第46条代表性样本作用下桥墩水平相对位移时程
Figure 12. Time-history of relative horizontal displacement of pier under the representative sample Article 46
图 13 非冻土情况下不同时刻桥墩相对位移转角的概率分布
Figure 13. Probability distribution of displacement Angle of bridge pier at different time under unfrozen soil condition
图 14 冻土情况下不同时刻桥墩相对位移转角的概率分布
Figure 14. Probability distribution of displacement Angle of bridge pier at different time under frozen soil condition
表 1 t-z 和q-z 曲线对照关系
Table 1. Relationship between t-z and q-z curves
t-z曲线 q-z曲线 z/d t/tmax z/d Q/Qp 0.0016 0.30 0.002 0.25 0.0031 0.50 0.013 0.50 0.0057 0.75 0.042 0.75 0.0080 0.90 0.073 0.90 0.0100 1.00 0.100 1 0.0200 0.70～0.90 0.200 1 — 0.70～0.90 — 1
下载: 导出CSV
表 2 钢筋混凝土本构参数
Table 2. Constitutive parameters of reinforced concrete material
混凝土 钢筋 参数 约束层 非约束层 参数 纵筋 箍筋 密度/(kg·m−3) 2.5×103 2.5×103 密度/(kg·m−3) 7.85×103 7.85×103 弹模/kPa 3.5×107 3.5×107 弹模/MPa 2.0×105 2.1×105 泊松比 0.2 0.2 应变硬化率 0.01 0.01 抗压强度/kPa 5.4×104 5.0×104 泊松比 0.3 0.3 峰值压应变 0.0025 0.002 屈服强度/MPa 400 300 抗拉强度/kPa 5.1×103 4.4×103 极限强度/MPa 570 420
下载: 导出CSV
表 3 不同抗震可靠度下桥墩相对位移转角阈值（单位：%）
Table 3. Threshold values of pier relative displacement Angle under different seismic reliability（Unit：%）
桥墩 抗震可靠度95% 抗震可靠度85% 抗震可靠度75% 非冻土条件 冻土条件 非冻土条件 冻土条件 非冻土条件 冻土条件 1号墩 4.42 4.34 3.92 3.78 3.64 3.51 2号墩 2.24 2.28 1.98 1.99 1.84 1.85
下载: 导出CSV
-
陈敦, 李国玉, 牛富俊等, 2023. 喜马拉雅山区公路桥涵病害类型及特征研究. 防灾减灾工程学报, 43(1): 18−31, 59. doi: 10.13409/j.cnki.jdpme.20220122001Chen D., Li G. Y., Niu F. J., et al., 2023. Damage types and characteristics of highway bridges and culverts in the Himalayas of China. Journal of Disaster Prevention and Mitigation Engineering, 43(1): 18−31,59. (in Chinese) doi: 10.13409/j.cnki.jdpme.20220122001 陈兴冲, 高峰, 王旭, 2003. 多年冻土区桥墩抗震性能研究. 岩石力学与工程学报, 22(S2): 2682−2685. doi: 10.3321/j.issn:1000-6915.2003.z2.030Chen X. C., Gao F., Wang X., 2003. Study on aseismatic property of bridge piers in permafrost region. Chinese Journal of Rock Mechanics and Engineering, 22(S2): 2682−2685. (in Chinese) doi: 10.3321/j.issn:1000-6915.2003.z2.030 陈兴冲, 高峰, 严松宏等, 2005. 多年冻土区桥梁的地震反应. 世界地震工程, 21(4): 26−31. doi: 10.3969/j.issn.1007-6069.2005.04.004Chen X. C., Gao F., Yan S. H., et al., 2005. Seismic response of bridges in the permafrost region. World Earthquake Engineering, 21(4): 26−31. (in Chinese) doi: 10.3969/j.issn.1007-6069.2005.04.004 陈兴冲, 高峰, 吴少海, 2007. 冻土层对桥梁地震反应的影响. 工程力学, 24(3): 120−125. doi: 10.3969/j.issn.1000-4750.2007.03.020Chen X. C., Gao F., Wu S. H., 2007. Effect of frozen soil layer on seismic response of bridges. Engineering Mechanics, 24(3): 120−125. (in Chinese) doi: 10.3969/j.issn.1000-4750.2007.03.020 李永波, 张鸿儒, 2015. 基于动力BNWF法的冻土-桩相互作用模型研究. 地震工程学报, 37(2): 453−459. doi: 10.3969/j.issn.1000-0844.2015.02.0453Li Y. B., Zhang H. R., 2015. Study on frozen soil pile interaction model based on dynamic beam on nonlinear Winkler foundation method. China Earthquake Engineering Journal, 37(2): 453−459. (in Chinese) doi: 10.3969/j.issn.1000-0844.2015.02.0453 刘章军, 曾波, 吴林强, 2015. 非平稳地震动过程模拟的谱表示-随机函数方法. 振动工程学报, 28(3): 411−417. doi: 10.16385/j.cnki.issn.1004-4523.2015.03.010Liu Z. J., Zeng B., Wu L. Q., 2015. Simulation of non-stationary ground motion by spectral representation and random functions. Journal of Vibration Engineering, 28(3): 411−417. (in Chinese) doi: 10.16385/j.cnki.issn.1004-4523.2015.03.010 刘章军, 刘增辉, 刘威, 2017a. 全非平稳地震动过程的概率模型及反应谱拟合. 振动与冲击, 36(2): 32−38. doi: 10.13465/j.cnki.jvs.2017.02.005Liu Z. J., Liu Z. H., Liu W., 2017a. Probability model of fully non-stationary ground motion with the target response spectrum compatible. Journal of Vibration and Shock, 36(2): 32−38. (in Chinese) doi: 10.13465/j.cnki.jvs.2017.02.005 刘章军, 刘子心, 2017b. 基于规范反应谱的全非平稳地震动过程模拟. 振动工程学报, 30(3): 457−465. doi: 10.16385/j.cnki.issn.1004-4523.2017.03.014Liu Z. J., Liu Z. X., 2017b. Simulation of fully non-stationary ground motion based on seismic design response spectrum. Journal of Vibration Engineering, 30(3): 457−465. (in Chinese) doi: 10.16385/j.cnki.issn.1004-4523.2017.03.014 祁鹏娟, 2021. 研究高寒冻土地区公路桥梁的病害机理及加固方法. 交通世界, (4-6): 151−152, 162. doi: 10.16248/j.cnki.11-3723/u.2021.z2.072 王海鹏, 毕树琦, 2010. 寒区桥梁超长桩承载力试验研究. 公路交通科技(应用技术版), 6(12): 231−233, 244. 王万平, 张熙胤, 王义等, 2022. 季节冻土区黄土抗剪强度变化特征及其影响因素. 哈尔滨工业大学学报, 54(8): 143−150.Wang W. P., Zhang X. Y., Wang Y., et al., 2022. Variation characteristics and influencing factors of loess shear strength in seasonal frozen soil region. Journal of Harbin Institute of Technology, 54(8): 143−150. (in Chinese) 武慧俊, 陈兴冲, 高峰等, 2005. 季节性冻土对桩基础桥墩地震反应的影响. 兰州交通大学学报, 24(6): 43−45.Wu H. J. , Chen X. C. , Gao F. , et al. 2005. Influence of seasonally frozen ground on seismic damages of pier with pile foundation. Journal of Lanzhou Jiaotong University, 24(6): 43−45. (in Chinese) 严松宏, 虞庐松, 陈兴冲等, 2008. 青藏铁路3种基础型式的桥墩地震反应分析. 铁道学报, 30(3): 78−82. doi: 10.3321/j.issn:1001-8360.2008.03.014Yan S. H., Yu L. S., Chen X. C., et al., 2008. Analysis of the earthquake responses of Qinghai-Tibet Railway piers for various foundations. Journal of the China Railway Society, 30(3): 78−82. (in Chinese) doi: 10.3321/j.issn:1001-8360.2008.03.014 虞庐松, 严松宏, 陈兴冲等, 2007. 多年冻土区桩基础桥墩随机地震反应分析. 世界地震工程, 23(1): 12−16.Yu L. S. , Yan S. H. , Chen X. C. , et al. 2007. Stochastic earthquake response analysis of bridge piers with pile foundation in the permafrost regions. World Earthquake Engineering, 23(1): 12−16. (in Chinese) Che A. L., Wu Z. J., Wang P., 2014. Stability of pile foundations base on warming effects on the permafrost under earthquake motions. Soils and Foundations, 54(4): 639−647. doi: 10.1016/j.sandf.2014.06.006 Chiou J. S., Ko Y. Y., Hsu S. Y., et al., 2012. Testing and analysis of a laterally loaded bridge caisson foundation in gravel. Soils and Foundations, 52(3): 562−573. doi: 10.1016/j.sandf.2012.05.013 Deodatis G., 1996. Non-stationary stochastic vector processes: seismic ground motion applications. Probabilistic Engineering Mechanics, 11(3): 149−167. doi: 10.1016/0266-8920(96)00007-0 Li J., Chen J. B., Fan W. L., 2007. The equivalent extreme-value event and evaluation of the structural system reliability. Structural Safety, 29(2): 112−131. doi: 10.1016/j.strusafe.2006.03.002 Rowley R. K., Watson G. H., Ladanyi B., 1975. Prediction of pile performance in permafrost under lateral load. Canadian Geotechnical Journal, 12(4): 510−523. doi: 10.1139/t75-057 Weaver J. S., Morgenstern N. R., 1981. Pile design in permafrost. Canadian Geotechnical Journal, 18(3): 357−370. -
