Effect of Saturated Complex Site on the Seismic Response of Continuous Long-span Beam Bridges
-
摘要: 我国沿海地区大量大跨桥梁位于饱和复杂场地，此类场地通常存在土饱和特性、起伏地形、上覆水层，其对地震波的散射效应将导致地震动空间变化，然而目前缺乏针对此类场地条件的实测地震记录。针对此问题，本文建立了适用于饱和复杂场地大跨桥梁抗震分析的多点地震动模拟方法。首先，基于边界元法求解饱和复杂场地地震动传递函数；然后采用谱表示法生成空间变化人工地震动加速度时程；最后，以五跨连续梁桥为例，开展大跨桥梁地震响应分析，研究局部场地效应、动水压力效应对大跨连续梁桥地震响应的影响规律。结果表明，饱和复杂场地地震动加速度峰值表现出明显的空间变化特性，多点输入可导致饱和场地中地震动峰值加速度放大2～3倍，进而引起墩顶位移较一致地震作用结果增大95%～110%；动水压力可引起墩顶位移、墩底内力增大34%、29%。饱和复杂场地大跨桥梁抗震分析时忽略场地条件对地震动、桥梁地震响应的影响偏于不安全。Abstract: In China, many long-span bridges are situated across saturated complex sites characterized by soil saturation, undulating topography and superimposed water, in which the propagation of seismic waves induces spatial variations in ground motions due to scattering effect. However, the seismic records under such specific site are lack. Addressing this concern, we establish a multi-point ground motion simulation approach to analyze the seismic response of long-span bridges in saturated sites. Initially, the boundary element method is employed to solve the ground motion transfer function of saturated sites. Subsequently, the spectral representation technique is used to synthesize spatially varying ground motion acceleration time-histories. Conclusively, a continuous five-span beam bridge is set as an example, and the seismic response is investigated to study the impact of local site effects and hydrodynamic pressures on the seismic behavior of the continuous beam bridge. The results indicate that the peak ground acceleration in the saturated regions has significantly spatial variances, and multipoint input can cause the peak acceleration of seismic motion in a saturated site to be amplified by 2~3 times. Consequently, situation leads to a 95%~110% increase in the displacement of the pier top compared to the results under uniform ground motions. Furthermore, dynamic hydrodynamic pressure is shown to precipitate pier displacement and internal forces by 34% and 29%, respectively. Disregarding the influence of saturated site conditions when evaluating ground motions and bridge responses for long-span bridges in saturated complex sites tends to engender hazardous outcomes.
-
图 3 地表点1、2、3地震动加速度自功率谱密度
Figure 3. Auto-power spectral density of ground motion acceleration of surface points 1, 2, and 3
图 4 不同地表点间地震动加速度互功率谱密度
Figure 4. Cross-power spectral density of ground motion acceleration among different surface points
图 9 多点、一致地震动作用下连续梁桥墩顶位移
Figure 9. Top displacement of the piers of the continuous beam bridge under multi-support and uniform ground motions
图 10 多点、一致地震动作用下连续梁桥墩底剪力
Figure 10. Shear force of the pier bottom of the continuous beam bridge under multi-support and uniform ground motions
图 11 多点、一致地震动作用下连续梁桥墩底弯矩
Figure 11. Moments of the pier bottom of the continuous beam bridge under multi-support and uniform ground motions
图 12 多点地震动作用下动水压力对连续梁桥墩顶位移的影响
Figure 12. Effect of hydrodynamic pressures on the displacement at the pier top of the continuous beam bridge
图 13 多点地震动作用下动水压力对连续梁桥墩底剪力的影响
Figure 13. Effect of hydrodynamic pressures on the shear force at the pier bottom of the continuous beam bridge
-
何颖, 于琴, 刘中宪, 2019. 考虑散射效应沉积河谷空间相关多点地震动模拟. 岩土力学, 40（7）: 2739—2747, 2788He Y. , Yu Q. , Liu Z. X. , 2019. Simulation of multi-point spatially correlated earthquake ground motions of sedimentary valleys considering scattering effect. Rock and Soil Mechanics, 40(7): 2739—2747, 2788. (in Chinese) 黄磊, 刘中宪, 张雪等, 2020. 含流体层的河谷场地对地震波散射的间接边界元法模拟. 地震学报, 42（6）: 657—668Huang L. , Liu Z. X. , Zhang X. , et al. , 2020. IBEM simulation of seismic wave scattering by valley topography with fluid layer. Acta Seismologica Sinica, 42(6): 657—668. (in Chinese) 李丽, 赵国峰, 李吉等, 2020. 一致激励与多点激励对悬索桥地震响应影响分析. 震灾防御技术, 15（2）: 252—259Li L. , Zhao G. F. , Li J. , et al. , 2020. Analysis of the influence of uniform excitation and multi-point excitation on the seismic response of suspension bridge. Technology for Earthquake Disaster Prevention, 15(2): 252—259. (in Chinese) 李平, 薄景山, 肖瑞杰等, 2018. 地震动河谷场地效应研究. 震灾防御技术, 13（2）: 331—341Li P. , Bo J. S. , Xiao R. J. , et al. , 2018. The study of effect by the valley site on ground motion. Technology for Earthquake Disaster Prevention, 13(2): 331—341. (in Chinese) 李伟华, 赵成刚, 2008. 平面SV波在饱和土半空间中圆柱形孔洞周边的散射. 地震工程与工程振动, 28（6）: 1—7Li W. H. , Zhao C. G. , 2008. An analytical solution for the scattering of plane SV-waves around cylindrical cavity in a fluid-saturated porous media half space. Journal of Earthquake Engineering and Engineering Vibration, 28(6): 1—7. (in Chinese) 李忠献, 李笑穹, 李宁, 2014. 空间相关多点多维地震动的模拟. 地震工程与工程振动, 34（4）: 64—72Li Z. X. , Li X. Q. , Li N. , 2014. Simulation of multi-point and multi-dimension spatially correlated earthquake ground motions. Earthquake Engineering and Engineering Dynamics, 34(4): 64—72. (in Chinese) 梁建文, 吴孟桃, 巴振宁, 2021. 流体饱和半空间二维地形三分量弹性波散射间接边界元模拟. 地球物理学报, 64（8）: 2766—2779Liang J. W. , Wu M. T. , Ba Z. N. , 2021. IBEM simulation of three-component scattering of elastic waves in a fluid-saturated half-space with 2 D topography. Chinese Journal of Geophysics, 64(8): 2766—2779. (in Chinese) 闫磊, 李青宁, 岳克锋等, 2019. 多维多点激励下考虑支座摩擦滑移及结构碰撞的非规则桥梁抗震性能研究. 世界地震工程, 35（2）: 68—77Yan L. , Li Q. N. , Yue K. F. , et al. , 2019. Seismic behavior of irregular bridges under multi-dimensional and multi-point excitation considering friction slip of bearings and structural pounding. World Earthquake Engineering, 35(2): 68—77. (in Chinese) Bi K. M. , Hao H. , 2012. Modelling and simulation of spatially varying earthquake ground motions at sites with varying conditions. Probabilistic Engineering Mechanics, 29: 92—104. doi: 10.1016/j.probengmech.2011.09.002 Huang H. C. , Chiu H. C. , 1995. The effect of canyon topography on strong ground motion at Feitsui damsite: quantitative results. Earthquake Engineering & Structural Dynamics, 24(7): 977—990. Li X. Q. , Li Z. X. , Crewe A. J. , 2018. Nonlinear seismic analysis of a high-pier, long-span, continuous RC frame bridge under spatially variable ground motions. Soil Dynamics and Earthquake Engineering, 114: 298—312. doi: 10.1016/j.soildyn.2018.07.032 Liu Z. X. , Li W. X. , Jin L. G. , et al. , 2023 a. Efficient simulation of stochastic seismic response of long-span bridges in river valleys using hybrid BEM-FEM. Soil Dynamics and Earthquake Engineering, 165: 107690. doi: 10.1016/j.soildyn.2022.107690 Sánchez-Sesma F. J. , Campillo M. , 1991. Diffraction of P, SV, and Rayleigh waves by topographic features: a boundary integral formulation. Bulletin of the Seismological Society of America, 81(6): 2234—2253. Wang P. G. , Zhao M. , Du X. L. , 2019. Simplified formula for earthquake-induced hydrodynamic pressure on round-ended and rectangular cylinders surrounded by water. Journal of Engineering Mechanics, 145(2): 04018137. doi: 10.1061/(ASCE)EM.1943-7889.0001567 Wu Y. X. , Gao Y. F. , Zhang N. , et al. , 2016. Simulation of spatially varying ground motions in V-shaped symmetric canyons. Journal of Earthquake Engineering, 20(6): 992—1010. doi: 10.1080/13632469.2015.1010049 Zanardo G. , Hao H. , Modena C. , 2002. Seismic response of multi-span simply supported bridges to a spatially varying earthquake ground motion. Earthquake Engineering & Structural Dynamics, 31(6): 1325—1345. -
